Siemens SDA 9064

The Siemens SDA 9064 is a Digital Deflection Controller IC designed for high-end television and monitor displays, specifically for 100-Hz and 120-Hz applications. It serves as a pipeline processor that controls various deflection stages to ensure precise raster alignment.

Key Specifications & Features

• Function: Controls horizontal and vertical deflection in CRTs, including raster alignment.
• Architecture: Built using NMOS technology with a pipeline processor structure.
• Package Types: Commonly found in P-DIP-40 (40-pin Dual In-line Package) or P-LCC-44 (44-pin Leaded Chip Carrier).
• Key Capabilities:
• Automatic or keyboard-controlled raster alignment.
• Adaptable beam current compensation for adjusting picture height and width.
• Supports high-frequency refresh rates (100-Hz/120-Hz) to reduce flicker.
