IPP075N15N3G - MOSFET Transistor, N Channel, 100 A, 150 V, 7.2 mohm, 10 V, 3 V

• MOSFET, N CH, 100 A, 150 V, INFINEON PG-TO220 - 3 IPP075 N15 N3 G • Manufacturer Name: INFINEON • Manufacturer Part No: IPP075 N15 N3 G Part NO. IPP075N15N3 G Package PG-TO220-3 Description MOSFET N-CH 150V 100A TO220-3 FET Type MOSFET N-Channel, Metal Oxide FET Feature Standard Drain to Source Voltage (Vdss) 150V Current - Continuous Drain (Id) @ 25° C 100A Rds On (Max) @ Id, Vgs 7.5 mOhm @ 100A, 10V Vgs(th) (Max) @ Id 4V @ 270µA Gate Charge (Qg) @ Vgs 93nC @ 10V Input Capacitance (Ciss) @ Vds 5470pF @ 75V Power - Max 300W Mounting Type Through Hole Supplier Device Package PG-TO220-3
